Explaining the appeal of the Morningstar MC6 Pro! What are the strengths of this next-generation MIDI foot controller? [Reviews and Uses]

One of the Morningstar MC6 Pro's greatest features is its three full-color LCD displays located in the center of the unit. You can freely edit the preset names and statuses associated with each switch, and they can also display real-time information like the current bank name, active effect name, expression pedal value, and tempo. While traditional MIDI controllers have small screens and limited information, the MC3 Pro's large, customizable display, including text, colors, and icons, allows you to intuitively grasp the status of even complex setups.

Additionally, the Color Strip function lets you assign a custom color band to each preset to group them, and visualize their on/off status with flashing or brightness. For example, you can color-code distortion to red, delay to blue, and so on, preventing accidental pressing and instantly checking their status. Visibility is excellent on stage, and users have praised it for letting you know at a glance which sounds are active.

The MC6 Pro offers high expandability, allowing you to assign multiple MIDI messages to a single switch and send them simultaneously with a single press. Each preset can store up to 1 different MIDI commands, allowing you to perform operations such as turning on delay, reverb, and switching amp channels all at once with a single switch.

Additionally, each footswitch can have a different preset depending on how it's pressed (action), allowing different control for each operation: press, release, double tap, long press, etc. This means that even though there are only six physical switches, they can effectively have 6 different functions. For example, you can set Switch A to "call a preset within a bank with a short press, and turn off all effects with a long press." It's this overwhelming flexibility that makes it known that "one unit can do everything."

The MC6 Pro packs one of the industry's most comprehensive connection ports into its compact housing. In addition to standard 5-pin MIDI IN/OUT, it also supports the 3.5mm TRS MIDI connectors that are becoming increasingly common in pedals these days. Additionally, the rear panel features four Morningstar-exclusive Omniports. These 4/1-inch TRS connectors can be individually configured as additional MIDI out connectors, expression pedal inputs, or external footswitch inputs, depending on your needs. For example, you can freely expand your setup with two expression pedals, one external switch, and one MIDI out.

Additionally, two relay ports are provided, allowing for control of things like channel switching on non-MIDI amplifiers and tap tempo input on non-MIDI pedals. Two USB ports are provided: the Device port connects to a PC or mobile device for DAW control or editor use, while the Host port allows for direct connection and control of USB-MIDI compatible effects (e.g., Source Audio, Line 2, ZOOM Multi, etc.). This means that USB-compatible pedals can be controlled directly from the MC2 Pro without the need for an additional USB host adapter. Power for the wireless MIDI adapter can also be supplied via the 6mm port, allowing for expandability in connection with any device, both wired and wireless. No other foot controller offers such a wide variety of connection options, and it has been described as "the most powerful and user-friendly MIDI controller ever made."

While a high-performance MIDI controller might sound like it would be difficult to set up, the MC6 Pro's user-friendly editor environment significantly lowers the programming hurdle. Morningstar offers a dedicated editor app (web/downloadable) for PCs and smartphones, allowing you to visually edit banks and presets via USB connection. The editor provides MIDI command templates ("MIDI dictionary") for each major effect unit and piece of equipment, and the required CC and PC numbers are automatically entered simply by selecting the corresponding device.

For example, by selecting a pedal name from a Strymon or BOSS brand, you can quickly select a list of MIDI commands corresponding to the pedal's tone switching and functions from a drop-down menu. Users have praised this feature, saying, "The extensive range of compatible devices makes setup extremely easy," and "Even MIDI beginners can use it without any trouble." In fact, one user commented, "The included web editor allows you to select hundreds of devices from a drop-down menu, making MIDI assignments surprisingly easy." SysEx message send settings, which can often be difficult to understand, are supported by templates, allowing for flexible control of advanced MIDI devices such as synthesizers. While setup can be performed directly on the unit without using the editor, this comprehensive software environment makes setup incredibly intuitive. Reviews include comments such as, "Even first-time MIDI users were able to understand it quickly" and "Programming was smooth," demonstrating that the MC6 Pro offers both advanced functionality and ease of use at a high level.
